4K SONY High frame rate USB Webcam Camera with Manual Varifocal Lens
4K SONY USB camera module with 2.8-12mm/5-50mm varifocal lens, IMX317 USB Webcam High frame rate 3840x2160 Mjpeg 30fps UVC Plug and Play
1.Packing list:
1) 1pc 4K camera module with 2.8-12mm/5-50mm varifocal lens
2) 1pc 3m usb cable
2.Key Specifications:
|
Model |
ELP-USB4KHDR01-MFV |
|
Sensor |
SONY IMX317 (1/2.5”) |
|
Max Resolution |
3840(H) *2160 (V) |
|
Sensitivity |
1000mV/Lux-sec |
|
Image area |
6100^mx4524^m |
|
Picture format |
MJPEG /YUY2 (YUYV) |
|
Resolution & FPS |
3840x2160@ 30fps MJPEG/ 2592x1944@ 30fps MJPEG 2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG 1920x1080@ 30fps MJPEG/ 1280x1024@30fps MJPEG 1280x960@30fps MJPEG/1280x720@ 30fps MJPEG 1024 x 768@ 30fps MJPEG/ 800 x 600@ 30fps MJPEG 640x480@ 30fps MJPEG/ 320x240@ 30fps MJPEG
3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY2 2048x1536@ 3fps YUY2 /1600x1200@ 3fps YUY2 1920x1080@ 3fps YUY2/ 1280x1024@3fps YUY2 1280x960@5fps YUY2/1280x720@ 5fps YUY2 1024 x 768@ 5fps YUY2/ 800 x 600@ 20fps YUY2 640x480@ 30fps YUY2 / 320x240@ 30fps YUY2 |
|
Center Definition |
1000LW/PH (Center) |
|
S/N (Signal Noise Ratio) |
26dB |
|
Sensitivity |
0.65V/lux-sec@550nm |
|
Low illumination |
0.2lux |
|
Shutter |
Electronic rolling shutter / Frame exposure |
|
Interface |
USB2.0 High Speed |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable Parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gama, White Balance, Backlight Contrast, Exposure |
|
Lens |
2.8-12mm/5-50mm lens optional Relative Illumination (Sensor): 70% IR Filter: 650±10nm |
|
Power Supply & Connector |
USB BUS POWER 4P-2.0mm socket |
|
Power |
DC5V |
|
Current |
200mA |
|
Size |
38mm x 38mm |
|
Storage Temperature |
-20°C to 70°C |
|
Working Temperature |
0°C to 60°C |
|
USB Cable |
1M(2M/3M/5M Optional) |
|
Operating System |
Win XP/Vista/Win7/Win8 / Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC |
Product Information
Product Information
Shipping & Returns
Shipping & Returns
4K SONY High frame rate USB Webcam Camera with Manual Varifocal Lens
4K SONY High frame rate USB Webcam Camera with Manual Varifocal Lens
4K SONY USB camera module with 2.8-12mm/5-50mm varifocal lens, IMX317 USB Webcam High frame rate 3840x2160 Mjpeg 30fps UVC Plug and Play
1.Packing list:
1) 1pc 4K camera module with 2.8-12mm/5-50mm varifocal lens
2) 1pc 3m usb cable
2.Key Specifications:
|
Model |
ELP-USB4KHDR01-MFV |
|
Sensor |
SONY IMX317 (1/2.5”) |
|
Max Resolution |
3840(H) *2160 (V) |
|
Sensitivity |
1000mV/Lux-sec |
|
Image area |
6100^mx4524^m |
|
Picture format |
MJPEG /YUY2 (YUYV) |
|
Resolution & FPS |
3840x2160@ 30fps MJPEG/ 2592x1944@ 30fps MJPEG 2048x1536@ 30fps MJPEG /1600x1200@ 30fps MJPEG 1920x1080@ 30fps MJPEG/ 1280x1024@30fps MJPEG 1280x960@30fps MJPEG/1280x720@ 30fps MJPEG 1024 x 768@ 30fps MJPEG/ 800 x 600@ 30fps MJPEG 640x480@ 30fps MJPEG/ 320x240@ 30fps MJPEG
3840x2160@ 1fps YUY2 / 2592x1944@ 1fps YUY2 2048x1536@ 3fps YUY2 /1600x1200@ 3fps YUY2 1920x1080@ 3fps YUY2/ 1280x1024@3fps YUY2 1280x960@5fps YUY2/1280x720@ 5fps YUY2 1024 x 768@ 5fps YUY2/ 800 x 600@ 20fps YUY2 640x480@ 30fps YUY2 / 320x240@ 30fps YUY2 |
|
Center Definition |
1000LW/PH (Center) |
|
S/N (Signal Noise Ratio) |
26dB |
|
Sensitivity |
0.65V/lux-sec@550nm |
|
Low illumination |
0.2lux |
|
Shutter |
Electronic rolling shutter / Frame exposure |
|
Interface |
USB2.0 High Speed |
|
AEC |
Support |
|
AEB |
Support |
|
AGC |
Support |
|
Adjustable Parameters |
Brightness, Contrast, Saturation, Hue, Sharpness, Gama, White Balance, Backlight Contrast, Exposure |
|
Lens |
2.8-12mm/5-50mm lens optional Relative Illumination (Sensor): 70% IR Filter: 650±10nm |
|
Power Supply & Connector |
USB BUS POWER 4P-2.0mm socket |
|
Power |
DC5V |
|
Current |
200mA |
|
Size |
38mm x 38mm |
|
Storage Temperature |
-20°C to 70°C |
|
Working Temperature |
0°C to 60°C |
|
USB Cable |
1M(2M/3M/5M Optional) |
|
Operating System |
Win XP/Vista/Win7/Win8 / Linux with UVC (above linux-2.6.26) MAC-OS X 10.4.8 or later/Android 4.0 or above with UVC |
